Bold Linkin Ltd Frame Set

About Bold Linkin Ltd Frame Set
The LINKIN 150 is Bold's approach to what the ultimate mountain bike should be. Long days in the backcountry, or just rippin' around your local, this 150mm trail platform brings the best out of every trail. Bold's integrated suspension design, ISTVP, keeps the center of gravity low between your feet to give the bike a planted but playful ride. An integrated "SAVE-THE-DAY" kit cleverly equips you with all the tools you'll need out in the woods. Is there such thing as n Swiss Army Knife of mountain bikes? If yes, there is a good chance it's the LINKIN 150.

Features
LINKIN Carbon HMX Frame

FOX Nude 5T Factory EVOL

Tracloc Remote Control Shifter Kit

Link kit for 135 & 150mm travel

Syncros Hixon iC Carbon

Syncros Duncan Dropper 1.5 34.9mm

Frame Geometry (units in mm unless otherwise indicated)

Frame	S	M	L	XL
Head Tube Angle (Degrees)	64.2/64.7	64.2/64.6	64.2/64.6	64.2/64.6
Head Tube Length	90	105	120	135
Top Tube Horizontal	547.1/545.5	596.2/594.5	629.3/627.5	662.5/660.7
Standover Height	683	715	740	766
BB Offset	-35.2/-29.0	-35.1/-28.8	-35.1/-28.7	-35.0/-28.5
BB Height	339.8/346.0	339.9/346.2	339.9/346.3	340/346.5
Wheel Base	1179.5/1181	1220.9/1222.4	1257.4/1258.9	1293.8/1295.3
BB Center To Top Of Seatube	365	395	425	455
Seat Angle (Degrees)	78.3/78.9	77.3/77.8	77.3/77.8	77.3/77.8
Chainstay	443.9/435.1	433.9/435.2	433.9/435.2	433.9/435.2
Reach	422/427.1	457.0/462.0	487.0/491.9	517.0/521.8
Stack	605.2/601.7	618.7/615.0	632.1/628.3	645.6/641.7
Stem Length	40	40	40	40
Maximum Seatpost Insertion	236	276	301	320

About Bold Cycles
Founded in Lengnau, a small village near the Jura Mountains in beautiful Switzerland in 2015, Bold Cycles are an innovative, cutting-edge bike company with the goal of providing riders with the most progressive, cutting-edge bikes on the market. They question design and technology and rethink the conventional by pushing through boundaries where innovation takes place and new rules are born.
